QUALITY AND AFFORDABILITY
With over 60 years of combined engineering and build experience in the manufacturing industry we are pleased to bring you our line of robot end-of-arm-tools. Our tools are pre-engineered and built to high quality standards but are priced affordably. We think you’ll find something that will fit your requirements. However if you do not, we can always custom design to suit your specific needs.
Get your FREE guide
Get this guide of factors to consider when selecting your palletizing tool
Palletizing
Cobot
New Bag Gripper
Description:
Our newest addition, medium duty cycle, bag gripper with adjustable width and a 25/50 kg payload for the palletizing of various bags.
You can change the bag width from 245mm to 590mm. Independently controlled deck plates provide better accuracy of the bag placement on the pallet. Repairable cylinders with band mounted sensors for easy position adjustment. Available options include, hooks for pallet pick up, retractable vacuum cups for slip sheet placement and pneumatic clamping to hold down the bag during robot transport.
Includes:
Robot mounting configured to your requirements.
Bag width adjustment with use of an allen wrench
Adjustable mechanical hold down
Independently operated deck plates
Solid stainless-steel gripper fingers, radiused ends to avoid bag damage
Repairable cylinders
One two station manifold with two 24vdc pneumatic control valves with pressure regulators, Multi-pin, Sub-D, 9-pin, 8 addresses, IP 40
Sensors wired back to I/O block
OPTIONS:
PHD, pneumatic hold down
PSS, pneumatic slip sheet
PPU, pallet pick up
Customization
SPECIFICATIONS:
MFF-50
Tool weight = ~65 kg
Max. payload = 25 kg
MFF-100
Tool weight = ~75 kg
Max. payload = 50 kg
